Description Network Ceiling Speaker ZYCOO SC15 is a compact high-performance SIP enabled ceiling speaker which can be used for SIP paging, notification/tone broadcasting and streamed high definition music playback. The high efficient, full-range drive units will provide you with a uniquely advanced listening experience. A p p l i c a b l e S c e n a r i o s Schools Health Care Shopping Centers Train/Bus Government Indoor Stations Offices Carparks Residential Buildings Retail Shops Airports Office Buildings Warehouses Hotels Audio Network Dual-speaker driver design – low frequency bass driver unit and high-frequency tweeter driver Provides premium sound quality, enhances the audience experience. Support ZYCOO BM11 Mic w/ Push-to-Talk Button, easy connection with the BM11 to achieve the talk- back ZYCOO IP Audio Center auto provisioning support, large-scale installations (local or remote) will be extremely easy and time-saving. Built-in SIP support, can be integrated with ZYCOO IP Audio Center or third-party SIP server, SIP paging using wideband 722 codec which provides crystal clear HD voice. Music playback through ZYCOO IP Audio Center using streamed HD MP3 audio files supported for superior quality of background music. Standard PoE (IEEE 3at) support, simple and easy installation with a single network cable. External power supply can be used if required. Support Multicast and Peer-to-Peer (P2P) to share data between devices without a central server while the devices use under the same local Built-in amplifier with local or server controlled volume output level, SC15 guarantees full and consistent coverage and also the audio comfort and the flab. Speaker SC15 supports three lines SIP accounts, in which users may register the endpoint in more than one system for achieving different functionality Speaker component: 5.25″ woofer unit 1″ tweeter unit Sensitivity: 85dB/1m/1W Max sound pressure level: 100dB Amplifier: Built-in Class D Amplifier Rated power: 8Ω 15W Frequency range: 70Hz – 20KHz Coverage pattern: 90°H 90°V 30m² Acoustics: Mono Audio codecs: G.722, G.711 A-law, G.711 U-law, Opus Audio streaming: MP3 sampling rate 8 – 48KHz, bit rate 64 – 320kbps, mono or Stereo Interface: RJ45 10BASE-T/100BASE-TX PoE Protocols: SIP(RFC3261), HTTP, TCP/IP, SSL, DNS, SNTP, NTP, RTSP, RTP, RTCP, TCP, UDP, MQTT, ICMP, DHCP, ARP, SSH Administration Mechanical Properties Environmental Configuration: Web interface or auto provisioning server Provisioning method: MQTT IoT Protocol Memory: 128MB RAM, 256MB Flash Power input: PoE IEEE802.3at or DC24V2A Casing: Surface-treated steel Grille: Surface-treated metal mesh plate Color: White Weight: 3.45KG (7.6lb) Dimension: φ240 x 210 mm (7.2 x 6.3 in) Mounting method: high strength anti-corrosion clamps Key: Press and hold for 3 seconds to announce IP address; Press and hold for 10 seconds to reset device to factory defaults. Installation environment: Indoor Operating temperature: -20℃ – 50℃ (-4℉ – 122℉) Storage temperature: -40℃ – 70℃ (-40℉ – 158℉) Humidity: 10% – 95% RH Non-condensing Approvals Approvals: EN 55032:2015, EN 55035:2017, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 62368-1:2014 A11:2017, FCC Part 15B Class A
