Description Specifications: CPU LGA1851 socket: Support for Intel® Core™ Ultra Processors L3 cache varies with CPU Chipset Intel® H810 Express Chipset Memory 2 x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity) of system memory Support for DDR5 6400/5600 MT/s memory modules Onboard Graphics 1 x DisplayPort (max. 3840×2160@60 Hz, DisplayPort 2.1) 1 x HDMI port (max. 4096×2160@60 Hz, HDMI 2.1) Audio Realtek® Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel LAN Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps) Expansion Slots (CPU) 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) Expansion Slots (Chipset) 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 (PCIEX1) Storage Interface 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) 4 x SATA 6Gb/s connectors, with RAID 0, 1, 5, 10 support USB (Back Panel) 2 x USB 3.2 Gen 1 ports, 4 x USB 2.0/1.1 ports USB (Internal Header) 1 x USB 3.2 Gen 1 header (for 2 ports) 1 x USB 2.0/1.1 header (for 2 ports) Back Panel Connectors 1 x DisplayPort, 1 x HDMI port, 2 x USB 3.2 Gen 1 ports, 4 x USB 2.0/1.1 ports, 1 x RJ-45 port, 3 x audio jacks Form Factor Micro ATX Form Factor; 22.6cm x 18.5cm Operating System Support for Windows 11 64-bit, Support for Windows 10 64-bit
