Description Features Long measurement distance, high measurement accuracy, high horizontal resolution Vehicle design standards, stable structure, lower power consumption Easier to mass produce and cost-effective Technical Specifications Scan Channel 32 Wavelength 905 nm Accuracy 2 cm Scanning Frequency 5Hz, 10Hz, 20Hz Horizontal Field of View 120 º Vertical Field of View -6.67 º to 4.58 º Power Supply Range 9 V to 36 V Power Consumption 100 W Shock 500m/ sec2, 3G rms Temperature -4 ºF to 149 ºF (-20 ºC to 60 ºC) Size 6.1 in x 4.2 in x 3.5 in (155 mm x 107.5 mm x 90 mm) Weight 3.3 lb (1.5 kg)
