Model No Zotac Geforce RTX 5060Ti 16GB Twin Edge OC Edition GDDR7 Graphic Card Part No ZT-B50620H-10M GPU NVIDIA GeForce RTX 5060 Ti GPU CUDA cores 4608 Video Memory 16GB GDDR7 Memory Bus 128-bit Engine Clock 2602 MHz Memory Clock 28 Gbps PCI Express PCI Express 5.0 x8 Fans 2 Display Outputs 3 x DisplayPort 2.1b with UHBR20 (up to 4K 480Hz or 8K 165Hz with DSC) 1 x HDMI® Connector (Supports 4K 480Hz HDR or 8K 120Hz HDR with DSC, and Gaming VRR as specified in the HDMI 2.1b Specification) HDCP Support 2.3 Multi Display Capability Quad Display Recommended Power Supply 600W Power Consumption 180W Power Input 1 x 8-pin power input DirectX Microsoft DirectX® 12 Ultimate OpenGL 4.6 Cooling IceStorm 2.0 Slot Size 2 slot Supported OS Windows 11 / Windows 10 64-bit (v1809 November 2018 or later) Special Features The ZOTAC GAMING GeForce RTX 5060 Ti 16GB Twin Edge OC is a compact graphics card powered by NVIDIA‘s cutting edge Blackwell Architecture, DLSS4 and 16GB of GDDR7 memory. With a factory OC as well as a solid cooling solution, the Twin Edge OC is ready to take on the latest title releases with smooth framerates and performance. - Powered by the NVIDIA Blackwell architecture and DLSS 4 - 8-Pin PCIe power connector - SFF-Ready Graphics Card - Compact dual-fan form factor - IceStorm 2.0 Cooling - BladeLink Fans - FREEZE Fan Stop - Metal Backplate - All-new FireStorm Utility Dimensions (W x H x D) 220.5mm x 120.25mm x 41.6mm / 8.7" x 4.7" x 1.6" Package Content User Manual Warranty 1 Year ( As per Manufacturer Policy ) Show More
